Sanitary Stainless Steel Tri Clamp Three Way Ball Valve
Sanitary Three Way Ball Valve with Mounting PadConnecting EndsClamped EndsStandardDIN, SMS, 3A, ISO, IDF, RJT, BSAvailable SizesDN25-DN100, 1"-4"Metal MaterialParts in contact with fluid304, 316L (DIN 1.4301, 1.4304) ForgingOther parts304Seal MaterialOptionsPTFEOperationManualPulling handl......
Send Inquiry
Product Description
Sanitary Three Way Ball Valve with Mounting Pad
| Connecting Ends | Clamped Ends | |
| Standard | DIN, SMS, 3A, ISO, IDF, RJT, BS | |
| Available Sizes | DN25-DN100, 1"-4" | |
| Metal Material | Parts in contact with fluid | 304, 316L (DIN 1.4301, 1.4304) Forging |
| Other parts | 304 | |
| Seal Material | Options | PTFE |
| Operation | Manual | Pulling handle |
| Pneumatic | NC, NO, A/A, A/S Actuator | |
| Electric | Actuator | |
| Pressure | Max. working pressure | 10 bar |
| Air supply pressure | 5~8 bar | |
| Surface Finish | Internal surface | Ra < 0.8 μm |
| External surface | Ra <1.6 μm | |
