Pneumatic V-Port Regulating Ball Valve/V Type Ball Valve/Ball Type Control Valve/Pneumatic Ball Valve/V Ball Valve/Pneumatic Actuator Ball Valve
Pneumatic V-Port Regulating Ball Valve/V Type Ball Valve/Ball Type Control Valve/Pneumatic Ball Valve/V Ball Valve/Pneumatic Actuator Ball ValvePneumatic V-port Regulating Ball Valve Main Parameters. Nominal pressurePN1.6~6.4MPaNominal diamete20~400mmAppliable TemperatureHard Seal:-40~300ºC......
Send Inquiry
Product Description
Pneumatic V-Port Regulating Ball Valve/V Type Ball Valve/Ball Type Control Valve/Pneumatic Ball Valve/V Ball Valve/Pneumatic Actuator Ball Valve
Pneumatic V-port Regulating Ball Valve Main Parameters.
Pneumatic V-port Regulating Ball Valve Product Feature.
1. The shear force between the ball and the metal seat type V incision, especially suitable for containing fiber and small solid particle, pulp and other medium.
2. Fully open flow capacity, small pressure loss, and the media will not deposit in the body cavity.
3. Using a spring-loaded movable seat structure , Preventing the occurrence of ball core and valve seat from jamming or other issues, reliable sealing and long service life.
4. The valve has the advantages of accurate regulation and reliable positioning function, approximately equal percentage flow characteristics, large adjustable range, the maximum adjustable ratio 100:1.
Nominal diameter DN, Rated flow coefficient Kv, Allowable pressure difference.
Pneumatic V-port Regulating Ball Valve Picture
More Products
About us
Pneumatic V-port Regulating Ball Valve Main Parameters.
| Nominal pressure | PN1.6~6.4MPa |
| Nominal diamete | 20~400mm |
| Appliable Temperature | Hard Seal:-40~300ºC Soft Seal: -40~180ºC |
| Applicable medium | Water,gas,oil quality and so on. |
| Driving Mean | Manual ,Electric, Worm wheels, Pneumatic |
| Body materials | WCB, CF8, CF8M, CF3M |
| Stem | 2Cr13, 304, 316 |
| Rotary angle | 90° |
| Core Material | CF8, CF8M, CF3M. |
Pneumatic V-port Regulating Ball Valve Product Feature.
1. The shear force between the ball and the metal seat type V incision, especially suitable for containing fiber and small solid particle, pulp and other medium.
2. Fully open flow capacity, small pressure loss, and the media will not deposit in the body cavity.
3. Using a spring-loaded movable seat structure , Preventing the occurrence of ball core and valve seat from jamming or other issues, reliable sealing and long service life.
4. The valve has the advantages of accurate regulation and reliable positioning function, approximately equal percentage flow characteristics, large adjustable range, the maximum adjustable ratio 100:1.
Nominal diameter DN, Rated flow coefficient Kv, Allowable pressure difference.
Pneumatic V-port Regulating Ball Valve Picture
