Home > Products > Ball Valve > Low Temperature Blow -out Proof Stem API 607 Fire Safe Investment Cast Steel A352 Lcb Lcc Body Stainless Steel Ball Rptfe Seat Insert Flanged Floating Ball Valve
Low Temperature Blow -out Proof Stem API 607 Fire Safe Investment Cast Steel A352 Lcb Lcc Body Stainless Steel Ball Rptfe Seat Insert Flanged Floating Ball Valve
AEA Cast Steel Floating Ball Valves are designed in accordance with ISO17292 featuring 2 pc split body or 3 pc split body, ideal for medium or high pressure services and wide temperature range (-196ºC~ 500ºC) . It can substitute the small size trunnion mounted ball valves to save c......
Send Inquiry
Product Description
AEA Cast Steel Floating Ball Valves are designed in accordance with ISO17292 featuring 2 pc split body or 3 pc split body, ideal for medium or high pressure services and wide temperature range (-196ºC~ 500ºC) . It can substitute the small size trunnion mounted ball valves to save cost.
Product Range
-Valve size:
1/2" ~ 10" (DN15-DN250)
-Pressure:
ANSI Class 150~2500(PN16-PN420)
-Temperature:
-196ºC~ 500ºC
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel
Trim: Carbon Steel, Stainless Steel, Duplex Steel
End Connection :RF, RTJ,BW, SW, NPT
Technical Specifications
-Design: ASME 16.34/BS 5351/API 6D
-Face to Face: ASME B16.10
-End Flange: ASME B16.5
-BW End: ASME B16.25
-Test: API 598/API 6D/ BS 6755
-Special: NACE MR-01-75
Design Features
-Full port or reduce port
- Fire Safe Design
-Blowout-proof stem
- Anti-Static Device
-Low emission control
-Optional locking device
-ISO 5211 top flange
Product Range
-Valve size:
1/2" ~ 10" (DN15-DN250)
-Pressure:
ANSI Class 150~2500(PN16-PN420)
-Temperature:
-196ºC~ 500ºC
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel
Trim: Carbon Steel, Stainless Steel, Duplex Steel
End Connection :RF, RTJ,BW, SW, NPT
Technical Specifications
-Design: ASME 16.34/BS 5351/API 6D
-Face to Face: ASME B16.10
-End Flange: ASME B16.5
-BW End: ASME B16.25
-Test: API 598/API 6D/ BS 6755
-Special: NACE MR-01-75
Design Features
-Full port or reduce port
- Fire Safe Design
-Blowout-proof stem
- Anti-Static Device
-Low emission control
-Optional locking device
-ISO 5211 top flange
