CNG Cylinder Valve with CE Certificated ( CTF -1)
Mingshi "QF-T" Series Compressed Natural Gas Cylinder Valves for Vehicles are suitable for switching gas flow on the cylinders whose operating medium is Compressed Natural Gas(CNG) with the operating pressure ≤ 20Mpa.Product No.QF-T1PN20MpaDN ≥ Φ 5mmExport Connecting......
Send Inquiry
Product Description
Mingshi "QF-T" Series Compressed Natural Gas Cylinder Valves for Vehicles are suitable for switching gas flow on the cylinders whose operating medium is Compressed Natural Gas(CNG) with the operating pressure ≤ 20Mpa.
| Product No. | QF-T1 |
| PN | 20Mpa |
| DN | ≥ Φ 5mm |
| Export Connecting Thread | 2-NPT1/4F |
| Joint Thread to Cylinder | GB8335 PZ27.8 |
| Temp/pressure of Safety Device | 33 ± 2Mpa, 100± 5° C |
| Suitable Medium | CNG |
| Surface Processing | Shot blasting or pickling |
| Body Material | HPb 59-1 |
| Working Temperature | -40° C - 60° C |
