China Rising Stem Flexible Seat Seal Gate Valve (RRHX)

Product Description

Full Rubber Wrapped: valve come is fully rappedbyhighperfromance rubber and latest vulcanization technology closely and firmly to effect accurate geonetrical dimensions, dependable seal and long service life.

Specifications
1) Size: 2" - 24"
2) Class: 150lbs - 600lbs

Technical standards:
1) Design and manufacture: API 6D
2) Face-to-face: ANSI B16.10
3) Flange end: ANSI B16.5
4) Inspection and test: API 598

Main materials:
1) Body and bonnet: Cast iron, ductile cast iron
2) Disc: Ductile cast iron coated with EPDM
3) Bonnet: Ductile cast iron
4) Stem: 2Cr13 / 420S

Note: We accept design and manufacture of various non-standard valves and arrange production according to users' supplied drawings and samples.

Suitable Medium	Water, Oil, Gas and etc.
Main material	Grey Cast Iron, Ductile Cast Iron, Carbon Steel, Alloy Cast Iron
Suitable Temperature	≤80
Nominal Pressure	150LB--900LB
Nominal Diameter	2"--24"
Flange Dimension	BS4504, ISO2531, ISO7005 and other standards conforming to the requirements
Face to Face Length	BS5155, ISO5752, DIN3352 and other standards conforming to the requirements
