Non Rising Stem Wedge Disc Gate Valve
Product basic descriptionStandard:Design standard conform to: MSS SP-67, API609, EN593Connection flange conform to: DIN PN10/16/25, ANSI B16.1, BS4504, ISO PN10/16,JIS B2212/2213, BS 10 Table D, BS 10 Table ETop flange conform to: ISO 5211Face to face conform to: API609, ISO5752 series 20, BS5155 Te......
Send Inquiry
Product Description
Product basic description
Standard:
Design standard conform to: MSS SP-67, API609, EN593
Connection flange conform to: DIN PN10/16/25, ANSI B16.1, BS4504, ISO PN10/16,
JIS B2212/2213, BS 10 Table D, BS 10 Table E
Top flange conform to: ISO 5211
Face to face conform to: API609, ISO5752 series 20, BS5155 Test standard conform to: API598
Design characters:
1. Equipment used in cutting off medium in pipeline.
2. Suitable for hand wheel, gear operators or electric actuators.
Performance:
Nominal Diameter: DN40-DN1200
Nominal Pressure PN (MPa):
1.0, 1.6, 2.0, 2.5
Testing pressure (water) Ps (MPa)
Body seat: 1.5 times rated pressure
Seat test: 1.1 times rated pressure
