Forged Pressure Seal Bonnet Socket Weld/Thread Gate Valve

API 602 CL800 FORGED FNPT/NPT/THREADED GATE VALVE Conform to API 600, ASME B16.34,  They are tested according to API 598, and marked as per MSS SP-25.



Construction is as follows:
- Full Port or Standard Port
- Bolted Bonnet with spiral-would gasket, threaded and seal welded bonnet and threaded and pressure seal bonnet
- Integral Backseat
 - Loose solid disc
- Butt Weld Ends to ASME B16.25

- Screwed Ends to ANSI/ASME B1.20.1
- Flanged Ends to ASME B16.5


 Normal Pressure Rating

PN10~PN420, CLASS150~2500
 Normal Size Range
