Cast Iron Resilient Seal Gate Valve
Introduction:Normal Presure: PN1.0MPaSuitable Medium: Water, Sewage, Air, Oil, Salts, etc.Temperature: Low than 120 degree centigrade.Size: DN40-DN300Standard:Flange Drilling: DIN2501; ANSI Class 125Face to Face: DIN3202; ANSI B 16.10Parts Material:Body: Cast IronWedge: CI, DI with EPDMStem: CS, SS4......
Send Inquiry
Product Description
Introduction:
Normal Presure: PN1.0MPa
Suitable Medium: Water, Sewage, Air, Oil, Salts, etc.
Temperature: Low than 120 degree centigrade.
Size: DN40-DN300
Standard:
Flange Drilling: DIN2501; ANSI Class 125
Face to Face: DIN3202; ANSI B 16.10
Parts Material:
Body: Cast Iron
Wedge: CI, DI with EPDM
Stem: CS, SS416
Seat: EPDM
Attention: According to customer's requirement, we can make any special kind of valves you need.
